1-1/2" Tube Socket Weld Stainless Steel Replacement Actuator-ready Ball valve

Model Number

1-1/2TSW F6-1.2-89-6-RTV-6-Z

Add to Cart
Request a Sample
Request a Sample
Product: 1-1/2" Tube Socket Weld Stainless Steel Replacement Actuator-ready Ball valve
Model Number: 1-1/2TSW F6-1.2-89-6-RTV-6-Z
11. Tell us about yourself
22. Request a sample
Configured Product Information
Spare Parts
Configured Product Information

Serviceable Series; three piece standard port 316 stainless steel ball valve. Seats and Stem Seal are glass reinforced P.T.F.E. (Teflon®), body seals Viton®. Pipe connections are tube socket weld. Temperature Range -20°F to 400°F (-28.8°C to 204.4°C). Valve Body Pressure Rating 1,000 psi C.W.P. (Cold Working Pressure), Maximum Pressure Differential 400 psi – also see Differential Pressure Temperature Chart), Saturated Steam to 150 PSI and a Vacuum rating of 20 Microns. Self-compensating stem seal design. Also see Product Specifications which can be found at Products are marketed per Gemini Valve Standard Terms & Conditions. All Gemini Valve Products MADE IN USA.

Valve operator is actuator drive key for use with pneumatic or electric Gemini actuator.

  • Valve TypeTwo-Way, On / Off
  • Valve StyleThree-Piece Body - Standard Port
  • Valve Connection Size1-1/2" Tube Socket Weld
  • Valve Port Size1.20
  • Valve Body Material316 Stainless Steel
  • Valve Ball & Stem Material316 Stainless Steel
  • Valve Seal MaterialP.T.F.E. (Glass Filled Reinforced Teflon®) / Viton®
  • Valve Temperature Range-20°F to 400°F (-28.8°C to 204.4°C)
  • Valve Pressure Rating1,000 PSI C.W.P. (Cold Working Pressure), Saturated Steam 150 PSI
  • Valve Vacuum Rating20 Micron
  • Spare Parts DescriptionBall Valve
